Jaeger - Unitek 04002895 Slide Out Seal

Today’s recreational vehicles offer a significant amount of features and amenities as many consumers seek the outdoor camping experience but want the same comfort as at home. One way in which a recreational vehicle can create more interior space is the “slide-out system”. While the “Slide-Out System” delivers an outstanding solution to maximize interior RV space, protecting the interior space from the outside elements creates a significant design engineering challenge. The sealing system plays a significant role in creating a watertight interior, minimizing temperature intrusions while delivering durability under dynamic and static loading conditions over a wide range of temperatures. By working closely with RV manufacturers in rapidly expanding the use of Jaeger Unitek Sealing Solutions Patented Flip ‘N Seal Slide-Out Sealing System ®, together, we have met the complex application demands with Slide-Out sealing requirements. For consumers, this translates into the growing use of RV slide-outs to create more interior space, protection from the outdoor elements, satisfaction and enjoyment in the great outdoors. The first polymer selection is one designed to provide a high modulus, combined with elongation characteristics to deliver stability and durability of the sealing system. Stripper seals for the side walls of the pull-out unit. Double wiper seals for the side walls of the extension unit. Pan gasket for the collecting trays of motorhomes.

• Excellent Adhesion To Surfaces Of Recreational Vehicles For A Secure Seal Against Mechanical Fastening Methods
• Resistance To Repeated Extraction At Temperatures From Negative-40 To Plus 90 Degree Celsius
• UV And Weathering Resistance For Waterproof Sealing Performance
• Design Freedom To Take Into Account The Significant Variations In Pull-Out Geometries And Dimensions Of Leisure Vehicles
• Damping Characteristics Which Cause An Interruption Of The Vibrational Forces While Driving And Thus Minimize The Energy Transfer To Other Of The Recreational Vehicle
• Heat Activated Bond Between The Inner Foam And The Polymeric Surface Of Forming A High Strength Sealing Barrier
• Use Of A Viscoelastic Foam Copes With Demanding Loads
• Offers The Elasticity To Functionally Seal If The Individual Components Have Different Coefficients Of Thermal Expansion During Temperature Changes
• Limited 45 Day Warranty
